Quality-assured DN50 PVC Pneumatic butterfly valves with 8 mounting holes
►Product Description
Model: D671X-10S
D: Butterfly valve
6: Pneumatic actuator operated
7: Wafer connection
1: Centric linear structure
X: Rubber seat(PTFE, EPDM, NBR)
10: Nominal pressure max. 10 bar
S: Plastic body (UPVC, CPVC, RPP, PVDF)
● Mounting to valve either directly or via bracket.
● Conforming to European and International Standard EN ISO 5211, preferred dimensions.
● Double Rack & Pinion design.
● Double acting or Spring return models utilize the same compact body design.
● Aluminum body, hard anodized externally and internally, for corrosion and wear resistance.
● Adjustable travel stops.
● Safe end cover bolting requiring no special tools.
● Anti blow-out drive pinion.
● Namur air connection can be easily mounted with solenoid valve.
● Parallel and diagonal, double square(star) drive.
● Travel adjustment (at each end) ±5°.
| Working Pressure | PN10 / PN16 |
| Testing Pressure | Shell: 1.5 times rated pressure, Seat: 1.1 times rated pressure. |
| Working Temperature | -10°C to 80°C (NBR) -10°C to 120°C (EPDM) |
| Suitable Media | Water, Oil and gas. |
►Company
FLOWAN AUTO-CONTROL is the professional actuator producing factory in WUXI, China for over 15 years,sales office is in WUXI, China . we manifacture all series of valves as below main types:
1, Pneumatic butterfly valve and pneumatic ball valve;
2, Electric butterfly valve and electric ball valve;
3, Actuator: pneumatic actuator, electric actuator;Hydraulic actuator;Electro-Hydraulic actuator;
4, Pneumatic diaphragm valve;
5, Pneumatic angle seat valve;
6, Solenoid valve;Limit Switch;Air filter;
7, Manual ball valve and manual butterfly valve.
| Structure | Butterfly valve, ball valve, gate valve, control valve, check valve, diaphragm valve and so on. |
| Actuator | Manual, Pneumatic, Solenoid, Electric, Motorized |
| Material | Stainless Steel, Plastic, Brass, Carbon Steel, PTFE, Metal, PVC, Iron and so on. |
| Medium | Water, Gas, Oil, Acid, Alkali, Corrosivity, Sewage, Power and so on. |
►Package
►FAQ
Q1: Are you trading company or manufacturer ?
A1: We are the manufacturer, specialize in VALVES & ACTUATORS for many years.
Q2: Do you have any certificates ?
A2: Yes,we have SIL&ISO&CE,"Quality is our culture".
Q3: How long is your delivery time
A3: Generally it is 7 days if the goods are in stock, otherwise it is 15-20 days, also according to your quantity.
